Description

• Complies with IEEE 802.11 a/b/g/n/ac standards
• Dual-Band Speed up to 2.4GHz 150Mbps, 5GHz 433Mbps
• Weatherproof RJ45 Connector, Integragted Passive Power over Ethernet (PoE)
• Passive PoE Support for Flexible Deployment
• Provides high performance at a Long-Range Links, depending on its antenna
• Features up to 1000mW of power and an enhanced receiver design
• Robust weatherproof case withstands harsh outdoor conditions
• Operation Modes: Router, AP, Repeater
• Maximum Security with WAP, and WPA2
• Support 3 LEDs Wireless Signal Strength
• Build in lightning arrester (15kV ESD)

TECHNICAL SPECIFICATIONS

• Model: WN570HA1
• Ports: 1 x 10/100Mbps WAN/LAN
• Buttons: 1 x Reset button
• LED
• 1 x Power
• 1 x WAN/LAN
• 1 x WiFi
• 3 x Signal
• Power Supply: DC24V / 0.5A Power over Ethernet ( Passive PoE)
• Rated Voltage / Frequency: input:100-240 Va.c. 50/60Hz
• Unit Dimensions: 180mm x 50mm x 50mm ( L x W x H )
• WIRELESS
• Standard: IEEE 802.11a/b/g/n/ac
• Speed
• IEEE 802.11ac: up to 433Mbps
• IEEE 802.11n: up to 150Mbps
• IEEE 802.11g: 54Mbps
• IEEE 802.11b: 11Mbps
• IEEE 802.11a: up to 54Mbps
• Frequency Band: 2.4GHz,5GHz
• Wireless Security: WPA-PSK/ WPA2-PSK encryption
• Antennas: 2 x 7dBi Detachable Omni Directional Antennas
• PACKAGE
• 1 x Wi-Fi AP/Range Extender/Router
• 2 x Detachable Omni Antenna
• 1 x RJ45 Networking Cable
• 1 x Power Adapter
• 1 x POE Converter
• 1 x Main body holder
• 2 x Cable ties
• 1 x Screw fittings
• 1 x Quick Guide
