Two way Solid State Relay Module

Name: Two way Solid State Relay Module - Dr Techlove
Brand: Module Board
SKU: C122-979855
Price: 18.14 AUD
Availability: InStock

or 4 payments of $4.54 with Wizit learn more

$18.14 AUD

Only 2 left in stock

SKU: C122-979855 Category: Module Board

Description

Description:

5V solid state relays 240V / 2A, output with resistive fuse 240V / 2A.

Dimensions: 55x33x25 (length x width x height)

Input Power: 5VDC

Control signal input voltage: (0-2.5V low state relay ON) (3-5V state high relay OFF)Feature:Voltage:5VQuiescent current: 0 mAOperating current: 12.5mATrigger Voltage: 3.3-5VTrigger current: 2mA

DC +: positive power supply (according to the relay voltage supply)

DC-: negative power supply

CH1: relay module signal triggering end (low to trigger active)CH2: relay module signal triggering end (low to trigger active)Package included:1 x Two way Solid State Relay Module For
