Description

OVERVIEW

Thanks to its small form factor the Focus+ Platinum 850 watt power supply is a mighty solution for those, who want to implement a smaller HTPC system or living room computer. This high quality unit is built with top-rated highly reliable aluminum electrolytic solid capacitors and it features Seasonic’s new cable-free connection design where the back panel and the PCB (Printed Circuit Board) are connected by a copper plate. This premium design feature is a breakthrough solution that lowers the chance of production errors and improves output power quality.

SPECIFICATIONS

• 80PLUS®: Platinum
• Form Factor: Intel ATX 12 V
• Dimensions: 150 mm (W) x 140 mm (L) x 86 mm (H)
• Fan Information
• Fan Size: 120 mm
• Fan Control: Hybrid Silent fan Control
• Fan Bearing: Fluid Dynamic Bearing
• Life Expectancy: 70,000 hours at 40 °C, 15 % – 65 % RH
• Cable Information
• Modularity: Fully Modular
• Cable type: Flat black cables
• Electrical Features
• Operating Temperature: 0 – 50 °C
• MTBF @ 25 °C, excl. fan: 100,000 hours
• AC Input: Full Range
• Protection: OPP, OVP, UVP, OCP, OTP, SCP
• Safety and Environmental
• Safety and EMC: cULus, TUV, CB, CCC, BSMI, EAC, RCM
• Environmental Compliance: Energy Star, RoHS, WEEE, ErP Lot 6, REACH
