Description

Material: Monocrystalline Silicon

Essential details

Brand Name:

Jink

Model Number:

JKM535M-72HLM-BDVP

Cell size:

182mmx182mm

Type:

Half Cell, Bifacial, Double-glass, All Black, N-TYPE

Panel Dimensions:

2096*1039*30mm

Panel Efficiency:

20.43%

Certificate:

TUV/CE/IEC/ISO

Warranty:

12 year

Cell Type:

P type Mono-crystalline

No. of cells:

144 (6*24)

Weight:

28.1kg (61.95 Ibs)

Front Glass:

2.0mm, Anti-Reflection Coating

Back Glass:

2.0mm, heat strengthened glass

Frame:

Anodized Aluminium Alloy

Junction Box:

IP68 Rated

Output Cables:

TUV 1*4.0mm2 (+): 250mm , (-): 150mm or Customized Length

Power Tolerance:

0~+3%

Packaging Configuration:

35pcs/pallets, 70pcs/stack, 770pcs/ 40’HQ Container
