Description




Geprc MARK4 225mm 5 Inch / 260mm 6 Inch / 295mm 7 Inch 3K Carbon Fiber Racing Frame Kit

Specification:
Brand Name: Geprc
Model: MARK4
Item Name: 225mm 5 Inch / 260mm 6 Inch / 295mm 7 Inch Frame Kit
Material: Full 3K Carbon Fiber
Wheelbase: 225mm / 260mm / 295mm ( Optional)
Frame Type: H type

Arms Plate Thickness: 5mm
Side Plate Thickness: 2.5mm
Top Plate Thickness: 2.5mm
Bottom Plate Thickness: 2.5mm
Protect Plate Thickness: 2mm

Size: 145*172mm@ 225mm ; 162*203mm@ 260mm ; 193*223mm@ 295mm
Weight: 102g@ 225mm ; 119g@260mm; 121g@ 295mm


Features:
– Super lightweight Freestyle frame
– Beautiful appearance design  , durable in crashing
– Quick maintenance Arms and replacement of equipment
– 25mm standoffs for better height and CG relation,Ample space for electronic installation
– Alu6061 Srandoff New , Strengthen the hardness
– There are 30.5*30.5 and 20*20 flight control holes , Stack can fit in the center or the rear.
– High quality 3K twill carbon fiber plate, high precision CNC processing
– YFS screw, 12.9 grade strength, non-slip teeth, anti-rust,Durable steel hardware



225mm 5 Inch Recommended Parts:
Flight Controller: RF/Kiss/F3/F4/F7
Motor:  2205/2206/2207/2207.5/2305/2306
ESC: 30A-50A
Propeller: 5inch
Lipo Battery: 4S 1500mAh ~ 6S 1150mAh


260mm 6 Inch Recommended:
Flight Controller: RF/Kiss/F3/F4/F7
Motor:  2207.5/2305/2306/2407
ESC: 35A-60A
Propeller: 6 inch
Lipo: 4S 1500mAh ~ 6S 1300mAh


295mm 7 Inch Recommended:
Flight Controller: RF/Kiss/F3/F4/F7
Motor:  2207.5/2305/2306/2408/2507
ESC: 40A-60A
Propeller: 7inch
Lipo: 4S 1800mAh ~ 6S 2200mAh

The following Parts are Compatible: ( Not Included)
FC & ESC & VTX:  LDARC 30.5×30.5mm F4 FC w/ 25/-600mW VTX & 40A ESC
                              HGLRC Titan Plus F460 Stack F4 FC & 60A BL_32 4in1 ESC

Brushless Motor:  Racerstar & T-Motor F40 II 2305 1600KV 4-6S Brushless Motor
                             HGLRC Forward 2408 1700KV 6S/ 2500KV 4S Brushless Motor

Propeller: 10 Pairs  LDARC 5×4.5×3 5045 5 Inch 3-Blade Propeller CW CCW
                Gemfan Flash 6042 6×4.2×3 6 Inch 3-Blade Propeller 2 CW & 2 CCW
                2 Pairs DALPROP CYCLONE T7056C 7inch Crystal 3-blade Propeller

Lipo Battery:  AHTECH Infinity 4S 14.8V 1500mAh 85C Graphene LiPo Battery XT60
                      Infinity 22.2V 6S1P 2200mah 70C Graphene Lipo Battery With XT60 Plug

Package Included:
1 x Geprc Mark4 5Inch / 6Inch/ 7Inch Frame

4 x 5*150  Nylon tie
2 x 20*220 GEPRC Lipo strap
1 x 15*250 GEPRC Lipo strap
1 x 2.4G Antenna fixed tube






Geprc MARK4 225mm 5 Inch / 260mm 6 Inch / 295mm 7 Inch Frame Kit for RC Drone FPV Racing 1
Geprc MARK4 225mm 5 Inch / 260mm 6 Inch / 295mm 7 Inch Frame Kit for RC Drone FPV Racing 2
Geprc MARK4 225mm 5 Inch / 260mm 6 Inch / 295mm 7 Inch Frame Kit for RC Drone FPV Racing 3
Geprc MARK4 225mm 5 Inch / 260mm 6 Inch / 295mm 7 Inch Frame Kit for RC Drone FPV Racing 4
Geprc MARK4 225mm 5 Inch / 260mm 6 Inch / 295mm 7 Inch Frame Kit for RC Drone FPV Racing 5

Additional information

Weight 0.12 kg
Length

5 inch, 6 inch, 7 inch
