Features :
2MP HD 1080P.
3.6mm lens.
Support WiFi 802.11b/g/n and AP point, support video record when network connection off.
With 2pcs White LED light & 2pcs IR led, full color night vision, IR distance 10-15m,make your night view as daytime.
Support Motion Detection/email alarm/app push.
Support two way audio.
Support max 128G TF card.
IP66 waterproof.
Support CMS viewing, APP viewing.
Support onvif, compatible with other devices.
Specification :
| Model : ESCAM QF508 | ||
| System | OS | Embedded Linux OS |
| Sensor | 1/4 1080p Progressive CMOS sensor | |
| Video | Compression Format | H.264 |
| Video coding | Main stream: 1920*1080@25fps; Sub stream: 640*480@25fps, 320*240@25fps | |
| Minimum illumination | 0.8Lux/F1.6 (colourful mode ), 0.3Lux/F1.6 (B&W mode) | |
| Lens/Viewing Angle | 3.6mm/62° | |
| Night Vision | Night vision | 2pcs IR LED and 2pcs White LED,10m IR distance |
| Audio | Compression format | G.711A |
| Input | Built in microphone | |
| Output | Built in speaker | |
| Network | Network Protocol | TCP/IP, HTTP, SMTP, DHCP, NTP, RTSP, etc. |
| Online visitor | Support 4 online visitors simutaneoursly | |
| IP address | Dynamic IP | |
| WIFI | WIFI 802.11 b/g/n, 2.4G WIFI | |
| AP Connection | Support AP connection | |
| Onvif | Support Onvif protocol | |
| Alarm | Motion Detection | Support motion detection |
| Alarm Action | Sending picture to Email; Saving video to TF card; APP push notification and buzzer | |
| Others | Storage | Support max to 128GB TF Card |
| Application environment | Indoor and outdoor | |
| Waterproof | IP66 | |
| Rated Voltage | DC 12V | |
| Temperature | -25 to 50 °C | |
| Humidity | 10-95%RH | |
| Power consumption | 6W | |
| Product size | 195x65x65mm (LxWxH) | |
| Product weight | 0.36kg | |
| Package size | 195x105x95mm (LxWxH) | |
| Weight | Gross Weight: 0.55kg (Note: in kind prevail) | |
| System Requirement | System configuration | Windows XP/7/8/10; IOS and Android |
Package includeds :
1 x ESCAM QF508 IP camera
1 x Waterproof hat
1 x Set of Screws
1 x Power Adapter (EU/US/AU/UK Plug for Optional)
1 x User Manual
