Description

Processor:
•Intel® Core™ i5-11400 processor (2.6GHz,up to 4.4GHz, TDP: 65W)

Memory:
•Dual channel DDR4
•Two 260 pins SODIMM sockets, support DDR4 up to 3200MHz (Real operation frequency depends on processor)
•Expandable memory up to 64GB, depends on 8GB/16GB/32GB SODIMM module

Video Controller:
•NVIDIA® GeForce RTX™ 3070 Laptop GPU
– Boost Clock 1560 MHz
– Maximum Graphics Power 115W
– 8GB GDDR6 Video RAM
– Support PCIe Gen4
– Microsoft DirectX® 12
– GeForce CUDA™ technology

Storage
•One changeable 2.5” 7mm(H) HDD / SSD, SATA interface
•(Factory Option) One M.2 2280 SSD,SATA interface or Two M.2 2280 SSD,PCIe Gen3 x4 interface (RAID 0/1)

Audio
• High Definition Audio
•S/PDIF digital output
•Built in array microphone
•Built in two speakers
•Sound Blaster™ Cinema 6

Keyboard and Pointing Device
•Multi languages Multi-Color illuminated full size keyboard with numeric pad
•Built in touch pad with Microsoft PTP multi-gesture and scrolling function

I/O ports
•1 x USB 3.2 Gen2x2 port (Type C)
•1 x USB 3.2 Gen 2 port (Type A)
•1 x USB 3.2 Gen 1 port (Type A)
•1 x USB 2.0 port
•1 x Mini Display 1.4 port
•1 x Mini Display 1.4 port
•1 x HDMITM output port (with HDCP)
•1 x 2-in-1 Audio Jack (Headphone / Microphone)
•1 x 2-in-1 Audio Jack (Microphone / S/PDIF optical)
•1 x RJ-45 LAN port
•1 x DC-in jack

Slot
•Three M.2 card slots
-1st for WLAN Combo M.2 2230 Card with PCIe / USB / CNVi interface (E key)
-2nd for SSD M.2 2280 Card with SATA / PCIe Gen3 x4 interface (M key)
-3rd for SSD M.2 2280 Card with PCIe Gen3x4 interface (M key)

Communication
•Built in 10/100/1000Mb Base-TX Ethernet LAN
•(Factory Option) Intel® Dual Band Wi-Fi 6 AX201 2×2 AX + BT CNVi M.2 2230 (Harrison Peak 2)
•(Factory Option) Intel® Dual Band Wi-Fi 6 AX200 2×2 AX + BT PCIe M.2 2230 (Cyclone Peak 2)
• (Factory Option) Intel®Dual Band Wireless-AC 9462 1×1 AC +BT M.2 2230 (Jefferson Peak 1)
•1.0M HD video camera

Power Supply
•Full Range AC adapter, AC in 100~240V, 50~60Hz, DC output 19.5V, 11.8A, 230W
•Removable 6 cells Smart Lithium-Ion battery pack, 62WH
•Battery life: 450 minutes (UMA mode with 62WH Battery)

Security
•Security (Kensington® Type) Lock Slot
•Intel® PTT for system without Hardware TPM

Others Design
•Metal (A)
•Shipping Mode
•FlexiCharger
•Virtual Reality ready via HDMI or miniDP from dGPU
•Intel® OptaneTM Technology (For Intel core processor family)
•Windows® Mixed Reality Compatible

O.S. Support
•Windows®10 20H2 (64-bit)
Certificate
•Windows®10 20H2 (64-bit) Logo
•HDMITM Logo
Dimension
•378 (W) x267 (D) x30 (H) mm (TBC)
Weight
•2.7 kg,including Barebone and 62 WH Battery (TBC)

Remark:
*Battery life may vary depending on applications and configuration.
*Weight tolerance is +/- 5%.
*The content is subject to change without notices. Other brand and product names are trademarks and/or register trademarks of their respective companies.
