Description
Key Features
The charging current of the DC charging station is large, ten times or even dozens of times the conventional charging current, and the charging speed is very fast, generally in 30 minutes for the electric vehicle to fill 80% of the charge, and then, from constant current charging to constant voltage charging to protect the battery, and charge the battery a little fuller .
DC charging station application place:
Special parking lot in the field of public service; Residential area; Enterprises and institutions; Urban public parking lots ; intercity highway service areas; shopping mall ;Hotel office building
| Specification | Model | 60kW, 120kW, 160kW ,82kW , 142kW, 182kW |
| AC Nominal Input | Phases/Lines | 3 phase+ neutral + PE |
| Voltage | 304~456V AC | |
| Frequency | 45-65Hz | |
| Output | Power | 60kW, 120kW,160kW ,82kW , 142kW, 182kW |
| Connector-single gun | CCS2, GBT, CCS1, CHAdeMO | |
| Connector-two gun | CCS2+CCS2, GBT+GBT, CCS2+GBT ,CC1+CCS2 ,CCS2+CHAdeMO | |
| Connector-three gun | CCS2+CCS2+AC type2, CCS2+GBT+AC type2, CCS2+CHAdeMO+AC type2 | |
| Voltage | 50VDC-1000VDC | |
| MAX Current | 180A+180A, 180A +125A, 200A+200A, 250A+250A, 200A+250A, 200A+125A | |
| Cable Length | 5m | |
| Electrical Parameter | Power Factor | ≥0.99 |
| THD Value | ≤5% | |
| Stable Voltage Accuracy | ≤±0.5% | |
| Stable Current Accuracy | ≤±1% | |
| Efficiency | ≥94% | |
| Structure Design | Module Number | 30kW+30kW |
| Installation Method | Vertical installation of ground | |
| LED Indicator | Green/Yellow/Red color for different states | |
| Display | One 7” Daylight readable Color Touch Screen | |
| Emergency Stop Button | Yes | |
| Payment Method | RFID Card/Phone APP with backend | |
| Communication | Charger v.s. Backend | Ethernet/GPRS/4G communication |
| Communication Protocol | OCPP1.6J | |
| Environmental index | Operating Temperature | -20ºC ~ +55ºC |
| Working Humidity | 5% ~ 95% no condensation | |
| Working Altitude | ≤2000m | |
| Protection Grade | IP54 | |
| Application Site | Indoor/Outdoor | |
| Cooling Method | The fan cooling | |
| Security Protection | Multiple Protection | Over/Under voltage protection, |
| Overload protection, Short circuit protection, Over/Under temperature protection, | ||
| Grounding protection, Surge protection, | ||
| Leakage protection | ||
| Warranty | 1 year | |
| Package Information | Product Dimension(W*D*H) | 700*400*1900mm, 700*600*1900mm |
| Net Weight | 260kg, 295kg, 320kg, 300kg, 355kg, 380kg | |
| External Packing | Wooden case |
