Description

Description:

The HDC1080 is a digital humidity sensor with integrated temperature sensor that provides excellent measurement accuracy at very low power. The HDC1080 operates over a wide supply range, and is a low cost, low power alternative to competitive solutions in a wide range of common applications. The humidity and temperature sensors are factory calibrated.Feature:

Relative Humidity Accuracy ±2% (typical)Temperature Accuracy ±0.2°C (typical)Excellent Stability at High Humidity14 Bit Measurement Resolution100 nA Sleep Mode CurrentAverage Supply Current:                                          710 nA @ 1sps, 11 bit RH Measurement                                          1.3 µA @ 1sps, 11 bit RH and Temperature MeasurementSupply Voltage 2.7 V to 5.5 VSmall 3 mm × 3 mm Device FootprintI²C InterfaceApplications:HVACSmart Thermostats and Room MonitorsWhite GoodsPrintersHandheld MetersMedical DevicesWireless Sensor (TIDA: 00374, 00484, 00524)Diagram:Package included:1 x Temperature And Humidity Sensor Module
