Description

Specification:1.Input Voltage: DC10-14V2.Standby Current: 90dBm6.Remote Control Distance: >100 meter(In open environment)7.Decoding Way: MCU Software decoding8.Can store the number of remote control:509.Support remote control type: Fixed code, learning code10.Channel: 1CH11.Multiple working modes: (Jog/Non-Latched ,inter-lock/Latched ,self-lock /Self-Latched,Delay off)12.Wiring Method:Fixed wiring terminal13.Working Voltage: DC12V14.Output Current: 10A15.Rated load:10A 250VAC / 10A 125VAC10A 30VDC / 10A 28VDC16.Output:Normally open,Common,Normally closed17.Dimension:3.5cm*3cm*1.6cmWorking/output way:1.Jog/Non-Latched: Press one button is Working /ON. Loosen your finger on the same button is Stop/OFF. One channel switch need one buttons remote control.2.Self -lock/Self-Latched: Press one button for one time is working/ON. Press the same button again is stop/OFF. One channel switch need one buttons remote control.3.Inter-lock /Latched: Press one button is working/ON, press another button is stop/OFF. One channel switch need 2 buttons remote control.4.Delay: Press remote control relay pull-in,release the remote control and begin timekeeping,after 5s,10s,15s will automatically close the relayDescription:1. press the learning code .the indicator flash ,loosen your finger ,press any button of the remote controlthe indicator flash 2 times and off .it mean you learn it successfully .2. it can learn more than 12 PCS 2262 or 1527 chip with the different code wireless 433MHz remote control3. remove/clean :press the learning button about 8 seconds , the indicator turn on to off, it means the information that you keep have been removed successfully . Package included:2 x 12V 1CH 433MHz Wireless Relay Switch Receiver
