Description:
Mini Pinhole HD 700TVL 1/3″ 3.7mm Wide Angle Board Lens CCTV Security PAL Camera
This item could used in any space like a hidden camera, it is included “DIY” cable because some time the space is too small for BNC
Features:
1.1/3 Inch CMOS HD Sensor.
2.700 TVL High Resolution.
3.Mini Illumination 0.01lux.
4.3.7mm Pinhole Lens 80 Degree.
5.Mini small size, Easy to use, Easy to Install.
Specification:
1.Image Sensor: 1/3″ CMOS Sensor
2.Horizontal Resolution: 700TV LINES
3.TV System: PAL
4.Pixels: PAL: 752Hx582V
5.Lens: 3.6mm Pinhole
6.Sync System: Internal
7.Usable Illumination: 0.01 Lux
8.S/N Ratio: More than 54dB (AGC OFF)
9.Gamma Correction: 0.45
10.Video Out: Composite Signal (1.0Vp-p, 75w)
11.Scanning System: PAL:625 Lines, 50 Field/Sec
12.Electronic Shutter Time: 1/50-1/100,000Sec
13.Operating Temperature: -10 degree~ +50 degree RH95% Max
14.Storage Temperature: 20 degree~ +60 degree RH95% Max
15.White Balance: Auto
16.Dimension(mm):36(L) x 36(W)mm
17.Power Supply: DC 12 V
18.Name:Mini camera
19.Model: 700TVL
Package Included:
1 x CMOS 700TVL 3.7mm Pinhole lens Camera(power adapter is not included)
2 x cable
